L-Acoustics KIVA

The L-Acoustics KIVA is the original ultra-compact line source speaker developed as part of the company’s WST (Wavefront Sculpture Technology) series, aimed at providing clear, consistent audio performance with elegant form factor for installations and touring. Designed to work in modular arrays, the KIVA uses dual 6.5″ low/mid-frequency transducers and a 1.5″ diaphragm compression driver loaded with the company’s proprietary DOSC waveguide for excellent horizontal coverage. Its lightweight design, weighing only 14 kg (30.8 lbs), allows for quick deployment and flexibility in various venue sizes and configurations. Though eventually succeeded by the KIVA II, the original KIVA still maintains its place in the market for users seeking compact, scalable sound reinforcement solutions with proven L-Acoustics engineering.

Performance-wise, the KIVA delivers a frequency response from 80 Hz to 20 kHz and is capable of reaching a peak SPL of 135 dB. It operates with 8 ohms nominal impedance and pairs effectively with LA4 or LA8 amplified controllers for optimal tuning and protection. The waveguide technology ensures 100° of horizontal directivity with focused vertical control when stacked in arrays, making it well-suited for venues requiring clarity and throw in both speech and music applications. The system’s modularity allows for easy configuration adjustments, while integrated rigging hardware makes setup intuitive for crews. Though compact, the KIVA can be used in large-scale applications when combined with SB118 or SB15 subs for extended low-frequency performance.

As of the current used equipment market, the original L-Acoustics KIVA system continues to be offered in full packages or as individual units. Pricing depends on condition, included rigging, amplifier compatibility, and accessories. A used set of 12 KIVA with flying hardware and cases may range between €12,000 and €18,000, depending on the seller and age of the gear. Pairing with matching LA4 or LA8 amplifiers is often included in larger turnkey system packages.

In summary, the original L-Acoustics KIVA remains a viable and respected solution for users needing compact, professional-grade line source arrays. While newer models like the KIVA II offer advancements in SPL and performance, the first-generation KIVA provides dependable sound quality and flexibility for a variety of applications at a more accessible price point on the used market.
