The Adamson CS7 is a powerful and compact column-style line array speaker system designed for touring, live performance, corporate events, installations, and houses of worship where both clarity and portability are essential. Featuring a modular 7-module mid/high column paired with optional subwoofer solutions, the CS7 delivers punchy sound with controlled directivity, offering 120° horizontal coverage and a focused vertical dispersion ideal for speech, music, and multimedia presentations. Built with Adamson’s acclaimed Wavefront Precision technology, the CS7 provides coherent wavefront alignment across the array for clear vocal reproduction and musical detail. With a maximum SPL of 138 dB, the system is capable of filling mid-sized venues of up to several thousand seats while maintaining excellent coverage consistency across the listening area.
Under the hood, each CS7 module houses a 1.4-inch compression driver loaded onto a precision horn and coupled with a rugged, lightweight 7-inch neodymium woofer, delivering detailed mid and high-frequency performance free from distortion. These modules are flown in a vertical array, creating a coherent line source that minimizes acoustic anomalies and improves off-axis clarity. The separate CS7-SB subwoofer options—available in powered (CS7-SB-P) and passive (CS7-SB) versions—feature dual 12-inch woofers with 4th-order bandpass enclosures. They extend low-frequency response down to 45 Hz and support cardioid array configurations, providing tight, focused bass with reduced stage bleed. Together, these subs add depth and impact that complement the focused clarity of the mid/high array, making the complete system a versatile full-range solution.
The CS7 is designed for fast and safe rigging with its robust integrated rigging hardware and ergonomic handles, enabling quick setup and teardown on tour or in installation. The powered subwoofer model includes onboard Class-D amplification and extensive DSP presets programmed specifically for the CS7 configuration, supporting automatic configuration of crossover, delay, EQ, and limiting. Additionally, the system is compatible with Adamson’s E-Force and H-Force amplification platforms, allowing flexible integration into larger multi-zone systems. Whether deployed in flown left-right stereo arrays, flown mono arrays with cardioid bass, or flown center arrays in theater setups, the CS7 delivers reliable, crisp, and articulate sound that meets the high demands of modern audio professionals.
In summary, the Adamson CS7 combines compact design, exceptional audio fidelity, and flexible rigging into a premium line array solution. With its modular mid/high column design, powerful sub-bass options, and built-in DSP intelligence, it’s engineered to excel in a wide range of performance environments—from foreground music reinforcement to articulate speech coverage. The system’s clarity, portability, and scalability make it a go-to choice for sound engineers seeking top-tier results in venues where precision and reliability are paramount.
